1508 series (¼"BSP)

Product description

¼"BSP Ceramic nozzles are mostly used in small bombs - granates - chain flails & spin jets to get a perfect performance.

Ceramic nozzles give an excellent jet - long life and are a "must" by using on a recycling unit.

Technical details :

• Dimensions : Hex 14 mm. length : 16 mm.
• Nozzle diameters: ø 0,70 / ø 0,80 e.s.o. up too ø 4,00 mm.
• Material : housing st. st. 303 / insert : ceramic.
• Part number 1508... (if you need ø 1,50 mm. part number is 1508.150)

• If you need the right tool for the right job, please use Socket wrench with cross handle 8025 for more information click here
• Blindplug : Hex.17 mm , length 25 mm. P/N : 304603

To disassemble an old insert it's recommended to heat the nozzle a little so the glue melts, clean the thread and glue the new insert with a drop of blue loctite 243, more info click here
