Hadescar
Product description
Hadescar special controlled rotating nozzle with flexible guide skid for large round - square and different shaped diameter pipe (tunnel) from 1000 up to 5000 mm. (200”) .
The 360 degree all around cleaning thoroughly removes hardened grease and some mineral deposits from the top of the pipe. Constructed of high-quality stainless steel and aluminum this flexible skid is adjustable within a 1/16” and very user-friendly.
Fit in manhole of 500 mm. and in 10 minutes operational.
Suitable by using 100% recycling water
- Inlet connection : 1¼"BSPF
- Nozzle patern : 5 x ¼"BSPF pulling + 4 x ¼"BSPF rotating (wall) in the nozzle head, option 6 x ¼"BSPF by using floor cleaner under frame.
- Suitable pump capacity min, 300 ltr./min. (67 gpm)
- Dimensions : 420 x 1000 mm.
- Weight : 40 kg.
- Complete kit excl. extension arms part number : 2550
- Extension arms ¼"BSPM/F length 25 mm. (require 4 pieces for 1 head) P/N : 5070
- Extension arms ¼"BSPM/F length 50 mm. (require 4 pieces for 1 head) P/N : 5072
- Extension arms ¼"BSPM/F length 100 mm. (require 4 pieces for 1 head) P/N : 5074
- Spare nozzle kop ( excl. extension arms & nozzles) P/N : 5020-10-001
- Spare nozzles ¼"BSPM hex 14 : P/N : 1508....
