Tank Cleaners A80R

160 Bar
Tank Cleaners A80R

Product description

The A80R special design for 360° cleaning of large tanks with hot water up to 90°C (195°F).

  • Water driven construction of stainless steel 303 with build in filter, cleaning tanks completely.
  • Can be used in tanks with small main hole (min, ø 165 mm.) , to protect the nozzle head and shaft you can use an stainless steel protecting cauge.
  • Capacity: 20 - 120 ltr./min at max. 140 bar (4,5 - 27 gpm at 2.000 psi)
  • Connection: ¾"BSP female
  • Small capacity use two nozzles and bigger flow 4 nozzles
  • A80R without injector set and nozzles P/N 890514
  • A80R excluded nozzles and blind nozzles calculated for flow and pressure :
  • 15 - 21 ltr./min. P/N 890500 + 2 mm. injector set
  • 20 - 25 ltr./min. P/N 890501 + 2,5 mm. injector set
  • 25 - 30 ltr./min. P/N 890502 + 3 mm. injector set
  • 30 - 40 ltr. /min. P/N 890503 + 4 mm. injector set
  • 40 - 50 ltr./min. P/N 890504 + 5 mm. injector set
  • 50 - 60 ltr./min. P/N 890505 + 6 mm. injector set
  • 60 - 70 ltr./min. P/N 890506 + 7 mm. injector set
  • 70 - 85 ltr./min. P/N 890507 + 8 mm. injector set
  • 85 - 120 ltr./min. P/N 890510 + 9 mm. injector set
  • Cauge Part number : P25482200



Video gives a test with the A80R 21 ltr./min. - 150 bar , temp 90°C,(890500) tank cleaner spins very controlled, redy to clean 10 tanks with a diameter of ± 4 mtr. in a food factory, first those tanks are cleaned with a gun at a temperature of 50°C , this is much better, easy and safe.

Documents

Video
